| Model |
MB560-VL |
| Order ID |
AC01-SP07H-P21 |
| Display |
2.8″ TFT Color LCD Screen (240*320) |
| Camera |
Binocular Camera @ 1MP WDR |
| Operation System |
Linux |
| Hardware |
CPU: Dual Core @1.0GHz RAM: 512MB; ROM: 8GB Speaker: 8ohm @1W Supplement Light: Yes Physical Keypad: 16 Keys Fingerprint Sensor: ZK Optical Sensor |
| Authentication Method |
Fingerprint / Face / Card / Password (Physical Keypad) |
| Fingerprint Capacity |
3,000 (Optional: 5,000) |
| Face Capacity |
3,000 (Optional: 5,000) |
| Card Capacity |
10,000 (1:N) |
| User Capacity |
10,000 (1:N) |
| Transaction Capacity |
100,000 (Optional: 200,000) |
| Max. User Password Length |
8 Digits |
| Biometric Authentication Speed |
<0.5 sec (Fingerprint), <0.35 sec (Facial Authentication) |
| Touchless Biometric Distance |
30cm to 200cm (Facial Authentication) |
| False Acceptance Rate (FAR) |
≤0.01% (Facial Authentication) ≤0.0001% (Fingerprint) |
| False Rejection Rate (FRR) |
≤0.02% (Facial Authentication) ≤0.01% (Fingerprint) |
| Biometric Algorithm |
ZKFace V4.0 ZKFingerprint V13.0 (Standard) / V10.0 (Optional) |
| Card Type |
ID Card @125 kHz (Optional) IC Card @13.56 MHz (Optional) |
| Optional Multi-Tech Module |
Module1: ID & IC & DESFire EV1/EV2 (125 kHz & 13.56 MHz Dual Frequency) |
| Communication |
TCP/IP1 Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional) Electric Lock1, Door Sensor1, Exit Button1 |
| Standard Functions |
ADMS, DST, Work Code, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Record Query, Tamper Switch Alarm, Multiple Verification Methods, T9 Keyboard Input, HTTPs / SSH Backend Access, Schedule Bell, Automatic Status Switch |
| Optional Functions |
125KHz ID Card (EM) / 13.56MHz IC Card / Dual Frequency ID & IC Card, Wi-Fi |
| Power Supply |
DC 12V 1.5A |
| Operating Temperature |
0°C to 45°C |
| Operating Humidity |
20% to 80% RH (Non-condensing) |
| Dimensions (LWH) |
170mm * 138mm * 38.55mm |
| Supported Software |
On-Premise: ZKBio Time / ZKBio CVAccess (TA Module) Cloud: ZKBio Zlink (Web Portal & Mobile App) |
| Installation |
Wall-mount |
| Certifications |
ISO14001, ISO9001, CE, FC |
